Fluid And Lube Handling
Click to view California Proposition 65 warning
High Flow Control Handle is designed for service where larger volume deliveries are required.
Used where metered fast delivery is required
Ideal for bulk fill, transfer, and high flow dispense:
Mining and construction vehicles
Lube and service trucks
Manufacturing plants
Compatible fluids:
Lubricants (up to SAE 140), Diesel, Oil, ATF,
anti-freeze (Glycol), Gear Oil Maximum viscosity SAE 140
Wetted materials:
Liquid Crystal Polymer (LCP), Aluminum, Buna-N™, Zinc Plated Steel, Stainless Steel
Features
- High volume rigid outlet with non-drip tip.
- Outlet with 3/4” NPT(F) connection thread and bonded seal to assure a leak free operation.
- Heavy duty rigid design
- Max Flow: 18.6 Gal/min. (70 L/min.)
- Max pressure 1,450 psi (100 bar)
- Swivel inlet 3/4” & 1″ NPT(F)
Technical
Power supply | air max. pressure 1450psi | V/Hz/A |
Weight approx. | 5 | lbs |
Dimensions (L x W x H) | 20 x 3.2 x 3.2 | inch |
