Fluid And Lube Handling
Click to view California Proposition 65 warning
CF50 is a high performance 1” AODD pump with many unique features. Similar to all our CF series pumps, the new CF50 utilizes a flow through fluid design that is more air efficient than traditional AODD pumps. Capable of distributing up to 50 gal/min. This equates to higher performance, versatility along with easy serviceability.
includes:
1120-037 Aluminum CF50 Diaphragm Pump
8134-005 LP Hose Assembly 5’ x 3/8”
8281-005 MP Hose Assembly 5’ x 1”
8182-005 LP Hose Assembly 5’ x 1”
4140-017 Cam-lock Coupler 1”
3260-035 F/R Auto Drain 3/8” NPT(F)
3230-022 LP Air Ball Valve 1” NPT(F) no bleed
4411-036 Mounting Bracket for AODD Pumps
3230-019 LP Air Ball Valve 1” NPT(F) no bleed
3120-219 Y-strainer 1" NPT(F)
Features
- Air inlet 3/8" NPSM (F)
- Fluid inlet port 1" NPT(F)
- Fluid outlet port 1" NPT(F)
- Max. free flow 53 Gal/min (200 l/min)
- Operating air pressure range 22 –102 PSI (1.5–7 bar)
- Solids in suspension 1/8" (3.2 mm)
- Wetted Materials Aluminum, Stainless steel, Hytrel, Acetal, and Buna-N
Technical
Weight approx. | 62 | lbs |
Power supply | 22 –102 PSI (1.5–7 bar) | V/Hz/A |
Dimensions (L x W x H) | 13 x 12 x 14 | inch |
