BenchRack systems are designed to hold and lift virtually any type of unibody or full-frame vehicle. Small cars to light trucks, vans and SUVs can be repaired in your shop. You can lift the vehicle when loaded on the ramps or on chassis pads, allowing access to the wheels and wheelwells. You can avoid interruptions from moving a vehicle between different work stations like for: disassembly, panel alignment and welding. BenchRack's versatility allows for all the work to be performed at one station - increasing productivity, saving time and money.



Features

• Universal solution for cars, vans, light trucks and SUVs.
• BenchRack models come with a scissor lift with tilt feature, making loading easier when approach space is limited.
• Machine-milled platform surface for precision repairs.
• Integrated lift allows technicians to work at their most comfortable height.
• Powerful 10-ton draw aligner pulls from any angle, 360 degrees around vehicle.
• Removable ramps allow better access to the vehicle.
• Flexible installation - either surface mounted with drive-on ramps or in-ground
• Compatible with the EVO universal anchoring, holding and fixturing system. No need to rent fixtures.
• Choose from several Car-O-Tronic measuring systems and you'll get precise vehicle information.



Technical

Max Weight Capacity	9,200	Lbs
Weight approx.	2,090	lbs
Power supply	220 3-phase / 50 or 110 1-phase / 60	V/Hz/A
Dimensions (L x W x H)	165 x 46 x 15	inch



Accessories

200-CAR30412	DrawLiner D16 Down Pull	$764.00	Add to cart
200-CAR30413	Down Pull for D91	$871.00	Add to cart
200-CAR30541	Accessories for Pulling Hook Kit T11	$1,113.00	Add to cart
200-CAR30638	Mounting Plate Specialty Clamp B248	$620.00	Add to cart
200-CAR30668	Distance 50mm B213	$278.00	Add to cart
200-CAR30872	Roll Stop/Loading Trolley	$942.00	Add to cart
200-CAR30948	Bench Parts B106/B39BR	$7,167.00	Add to cart
200-CAR31040	Cable Guard	$161.00	Add to cart
200-CAR31927	Ramp Kit for BenchRack 4200	$7,158.00	Add to cart
200-CAR32856	Mounting Plate B264	$298.00	Add to cart
200-CAR35395	E130 Chain Holder for EVO	$354.00	Add to cart
200-CAR41303	Cab on Complete Frame Kit E390	$29,708.00	Add to cart
