X9-3ADPMAZ Brake Lathe (Replaces PC1923MAZ)

Call for price

38-X9-3ADPMAZ
Pro Cut International LTD LLC

Request a call

Neutral Hold Mode Note for CX-90 & CX-70 Brake Lathe:

  • The vehicle can be stopped with the shift in Neutral (N) and the electric parking brake (EPB) released using "Neutral Hold Mode" (refer to MGSS).
  • During this mode, the AUTO P (parking lock) and Anti Roll Away functions are disabled, and the ignition switches to ACC.
  • Neutral Hold Mode lasts about 25 minutes; if left active, AUTO P and Anti Roll Away will automatically engage.

This ensures safe and efficient use with the brake lathe.
For more detailed information, click here to be redirected to the Workshop Manual in MGSS




X9 Brake lathe with accessories and 3 Mazda adapters.

The PFM X9 combines our best existing technologies, like patented PFM one button computerized compensation system and 4 wheel-4 axis fully adjustable trolley, and combines them with a rigid new X-Frame lathe chassis, powerful belt driven high-torque drivetrain, and super bright 6 LED light to give you a clear path to higher profits! All X9’s come with our famous DRO display that includes live run-out, productivity tracking, and lathe diagnostics. X9’s are digitally expandable to optional G2X and GYR systems.



Features

  • Patented one touch Lateral Run Out (LRO) compensation - Press one button and the latest PFM lathes compensate in less than 20 seconds!
  • DRO “Live” digital computer display - Displays actual live LRO of machine & tracks # of compensations and duration.
  • Custom Calibrated Rate Sensor - Locks lathe in at .001” or less LRO every time you compensate for factory perfect cuts.
  • 4 Wheel, 4 Axis, Adjustable Trolley - Working Range of 21”to 43” allows the use on any lift or no lift!
  • 6 LED on-board work light - Improves technician safety and efficiency in dark wheel wells.
