TC33 Base Tire Changer

Login for special pricing

Hunter Engineering Company
Made In The USA
Click to see additional Options / Models / Accessories Available
Options Accessories

Request a call



The TC33 series retains the simplicity of the TC3300, while introducing features like a three-position platen, optional wheel lift & dual optional press systems. Center clamp with cam plate, 10-26” wheel diameter, integrated blast inflation, standard polymer head, PowerOut Side shovel.



Features

  • Floating 3-Point Arm - Faster than swing-arm designs, Follows rim for ultimate protection.
  • Convenient Storage - Store tools and accessories within arm’s reach.
  • 3-Position Platen Height - Adjusts for operator comfort & Allows wide range of wheel widths.
  • Wheel Protection - Clamps through hub, not to rim edge , All contact surfaces polymer protected , and Cam plate keeps wheels secure.
  • Motor and Drive - Powerful 220V motor, Fully-variable 0-14 RPM clockwise, 14 RPM counterclockwise, and 867 ft-lbs. of torque.
  • Center Clamp Simplicity - Cam action multiplies clamping force,No need for flange plates on most reverse wheels.
  • Built-In Blast Inflation - Directs bursts of compressed air to easily seat the bead.



Technical

Tire diameter 50 inch
Weight approx. 660 lbs
Color Hunter Red
Power supply 220V 6A, L6-20P plug V/Hz/A
Dimensions (L x W x H) 57 x 29 x 70 inch



Options

1-TC33BP TC33 Tire Changer with Bead Press Login for special pricing Add to cart
1-TC33M TC33 Mobile Tire Changer Login for special pricing Add to cart
1-TC33MBP TC33 Mobile Tire Changer with Bead Press Login for special pricing Add to cart
1-TC33PL TC33 Tire Changer with Plus Device Login for special pricing Add to cart



Accessories

1-20-3442-1 Wheel Lift Login for pricing Add to cart
1-20-3781-1 Bead Press Kit Login for pricing Add to cart
1-20-3782-1 Plus Device Kit Login for pricing Add to cart
1-RP6-G1000A11 High-Performance Bead Lever Login for pricing Add to cart
1-RP6-G1000A7 Mechanical Bead Roller Login for pricing Add to cart
1-RP6-G1000A87 Flange plate for chrome-clad and reverse wheels Login for pricing Add to cart
