Tiger HP 6:1 Oil Pump with Bung Adapter
Call for price
Click to view California Proposition 65 warning
The 6:1 ratio Tiger HP® pump can service as many as six simultaneous dispense points or transfer oil to distances up to 700 feet. Maximum simultaneous dispense points @ 1.5 gal/m (5.7 l/m) per dispense point. Note: pumping distance and pipe diameter will affect dispensing performance.
The Tiger HP® air motor features a precision air valve mechanism with dual valve ports for improved high-speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) by preventing the pump from stopping between strokes. It has a simple yet durable construction with all internal parts lubricated at the factory using a life-tested synthetic grease.
The Tiger HP® pumping assembly features a stainless pump rod for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft-grade extruded aluminum for outstanding strength and reliability. The pump also has high-quality seals and is designed for long-term durability and ease of service. It is equipped with internal pressure relief to protect the system from thermal expansion.
Features
- Operating air pressure range: 40–150 PSI (3–10 bar).
- Pump delivery with SAE 10W30 oil, 68º F (20º C), 100 psi (7 bar) air pressure and free flow 16 gal/m (61 l/m).
- Air consumption 100 psi (7 bar) and 8 gal/m (30 l/m) 59 SCFM.
- Max fluid stall pressure @150 psi (10 bar) air 870 PSI (60 bar).
- Wetted materials - Carbon steel, Buna-N™ Stainless steel, Nickel plated steel, Nylon, Ultrathane, and Viton.
- 31 Cycles per Gal.
- Air Inlet - 3/8” NPT (F).
- Fluid Inlet - 1” NPT (F) 1-1/2” NPT (M).
- Fluid Outlet - 3/4” NPT(F).
- Effective Air Piston diameter - 3.2” (81 mm).
Technical
Dimensions (L x W x H) | 25.72 H x 5.82 W | inch |
Power supply | Air | V/Hz/A |
Weight approx. | 39 | lbs |
Accessories
44-3230-018 | In-Line Hand Operated Valve for Air - 1/4" - 580 PSI | $13.00 | Add to cart |
44-3230-019 | In-Line Hand Operated Valve for Air - 3/8" - 580 PSI | $17.00 | Add to cart |
44-3230-020 | In-Line Hand Operated Valve for Air - 1/2" - 580 PSI | $18.00 | Add to cart |
44-3230-021 | In-Line Hand Operated Valve for Air - 3/4" - 580 PSI | $23.00 | Add to cart |
44-3230-022 | In-Line Hand Operated Valve for Air - 1" - 580 PSI | $36.00 | Add to cart |
