NON-METERED CONTROL HANDLE W/FLEX MEMORY 1/4TURN MANUAL NOZZLE - ATF

Call for price

44-3320-032
Balcrank Corporation
Made In The USA

Request a call



Click to view California Proposition 65 warning



Features

  • Non-metered control handle for ATF flex-memory 1/4turn narrow extension/tip
  • Large port, ball bearing, inlet swivel included
  • Easy access fluid inlet screen included at swivel
  • Included swivel hose-end cover, protects vehicle or machine surfaces from scratches
  • Easy access for service of the rotary-piston mechanism
  • Trigger lock button prevents accidental control valve opening and allows the control valve to be locked in open position for large volumes dispense
  • Cam & Piston valve design optimized for superb control and minimum flow resistance
  • Ergonomically designed grip handle for optimum comfort
  • Flow Rate 0.25-8 G/M (1-40 L/M)
  • Max pressure 1,450 PSI (100 bar)
  • Swivel inlet 1/2″ NPT(F) Swivel
  • Operating temp 14°F-140°F (-10°C-70°C)



Technical

Weight approx. 3.5lbs lbs
Dimensions (L x W x H) 19in L x 2in W inch
Power supply air max. pressure 1450psi V/Hz/A
