Engine and Transmission Repair Stand by Werner Weitner

Call for price

521-WW-MG-600V
Reliable Automotive

Click to see additional Options / Models / Accessories Available
Accessories

Request a call



Applicable in all automobile workshops. Developed for repairing engines and transmissions, up to 1,102 lbs/500 kg (especially for 8 up to 12 cylinders). Easy to maneuver even with engine or transmission placed in the stand. 360-degree rotation with load. Compact space-saving design. Self-locking worm gear and lockable rear wheels allow safe positioning. Hydraulic adjustment of load holder height up to 180 mm. Ready to use with removable oil pan and handy tool rack. Engine and transmission support sold separately.



Features

  • 360° rotatable
  • Single-person operation
  • Adjustable height
  • Time and space saving
  • Safe in all positions
  • Waste oil pan and tool rack
  • Ready to use with oil pan and tool rack
  • Max. Width: 31.1" (790 mm)
  • Max. Length: 41.73" (1060 mm)
  • Total Height at Center: 35.43" (900 mm)
  • Flange diameter: 8.66" (220 mm)
  • Load capacity: 1,322 lbs. (600 kg)



Technical

Weight approx. 220.462 lbs



Accessories

521-WW-6-140K Universal Engine Adapters $1,575.00 Add to cart
521-WW-GA-400 Universal Motor and Transmission Support $1,976.00 Add to cart
521-WW-GA-400-13 Locking Bolt $122.00 Add to cart
